Dissolved Air Flotation Equipment
Dissolved air flotation is mainly applicable to the treatment of various types of wastewater with a floc density close to water after reaction. It is widely used in machinery, chemical industry, textile, transportation, food and other industries, especially for oilfield...
Send InquiryDissolved air flotation equipment introduction
The equipment is mainly composed of sewage pump, metering device, dosing tank, reaction tank, air floatation tank, air floatation system and electric control system. The main treatment process adopts physical chemical method.
Technical Data
Product detail
Original: Jiangsu, China
Certification: ISO9001, ISO14001, etc.
Price: Negotiable
Material: SUS304/Q235/FRP
Voltage: 380V 50Hz, the voltage can be as local demand
Payment term: TT, LC
Delivery date: Negotiable
Packing: export standard
Market: Middle East/ Africa/Asia/South America/Europe/North America
Warranty: 1 year
MOQ: 1 set
Equipment characteristics
Dissolved air flotation can remove grease, jelly, solid suspended solids, BOD and COD in sewage. Using it to treat mid-stage wastewater and white water can greatly reduce the scale of biochemical secondary treatment equipment, thereby greatly reducing the overall investment cost. Air floatation greatly reduces the investment cost of sewage pretreatment.
Contrary to traditional grease collectors, air floatation removes solid sludge from the wastewater automatically and continuously. Sludge removal and storage is carried out in a concentrated manner. The high concentration of the floating sludge collected by this equipment can reach about 5%, so the cost of sludge treatment is also reduced.
The treatment capacity of air floatation is 5-2000m³/hr. According to customer requirements, different flow devices can be designed. The amount of incoming water does not need to be balanced. Even if the flow rate changes, the equipment can work normally. Under normal circumstances, the removal rate of grease and solid suspended solids (SS) exceeds 95%.
Product Advantage
Dissolved air flotation has the characteristics of simple and reasonable process, wide adaptability, compact structure, convenient transportation and installation, easy operation, stable and reliable performance.
