Stainless Steel Biosafety Cabinet

1.Stainless steel biosafety cabinet i ntroduction Stainless steel biosafety cabinet is high temperature resistant, strong acid and strong alkali, suitable for high temperature and concentrated sulfuric acid, nitric acid and other operations. Applicable to all kinds of high...

Send Inquiry
Product Introduction

1.Stainless steel biosafety cabinet introduction

Stainless steel biosafety cabinet is high temperature resistant, strong acid and strong alkali, suitable for high temperature and concentrated sulfuric acid, nitric acid and other operations. Applicable to all kinds of high cleanliness laboratories such as trace metal laboratory, pharmaceutical laboratory, biological laboratory, semiconductor laboratory, widely used in chemical industry, medicine, automobile, steel factory, University and scientific research institutions and other industries.

2.Technical parameters




H×L×W (MM)


H×L×W (MM)

Air quantity


static pressure






>1080 m3/h






>1350 m3/h






>1620 m3/h


3.Product detail

Original: Jiangsu, China

Certification: ISO9001, ISO14001, etc.

Price: Negotiable

Material: SUS304/316

Payment term: TT, LC

Delivery date: Negotiable

Packing: export standard

Market: Middle East/ Africa/Asia/South America/Europe/North America

Warranty: 1 year

MOQ: 1 set

4.Equipment characteristics

1.[overall material]

Upper cabinet body: The shell is made of 1.0mm #304 stainless steel after CNC machining center, cutting, positioning drilling, bending and welding, and has beautiful appearance. The inner shell is made of 1.0mm #304 stainless steel. A removable maintenance hole is provided for easy maintenance of circuits, waterways and gas roads.

1.0mm #304 stainless steel sheet, corrosion resistance, high acid and alkali resistance, impact resistance, easy to clean.

Lower cabinet body: lower cabinet body (general bottom cabinet), door plate: 1.0mm stainless steel (double layer), no welded connection with detachable cushion. Good load-bearing capacity can be obtained in CNC machining center, cutting, positioning drilling, bending and welding.

2.[sliding door system]

Guide: special PVC material and line contact design are adopted to minimize friction.

Window handle: stainless steel matte handle, beautiful and generous.

Windows: Aluminum profiles with plastic profiles frame, window using 3 5 mm safety glass, can move left and right, and use no-segment balancing device, can move up and down, free adjustment. 1.0mm #304 stainless steel for sliding glass handle and window glass frame.

Pull rope: SUS304 outsourced PVC (top configuration in laboratory fume hood).

Pulley: PP silent pulley, friction is very small.

Counterweight block: SUS304 shell for easy adjustment.

3.[electronic devices]

Illumination: the fluorescent lamp is hidden on the panel and is not easily contacted with the air flow in the stainless steel hood. Adopt 2 36W fluorescent lamps and 5mm toughened glass.

Socket: special socket for laboratory.

Distribution box: in line with 220V and 380V power supply requirements, leakage and motor protection device. (all electrical appliances are absolutely brand products, and we always attach importance to safety issues).

Controller: Integrated controller panel with LCD function, visual control of various parameters, so that your operation can be assured.

4.[other accessories]

Door handle: stainless steel matte handle.

Hinges: Guangdong Dongtai DTC hinge, beautiful appearance, no noise when opening and closing, more than 50,000 times, rust-proof, corrosion resistance, to meet the international hardware industry standards.

Gas collecting hood: acid resistant alkali stainless steel, standard 250MM outlet (outlet size can be customized according to requirements).

Guide clip: 1.0mm #304 stainless steel. The three guide plates adopt stainless steel of 1.0mm # to discharge harmful gases from different sections in different altitudes. The air in the fume hood is discharged at the speed of 0.5m/s on the operating surface to ensure that no residual gas exists. The ventilation efficiency is high, the exhaust volume is about 1600m3/h, and the noise is small.

5.[optional configuration]

Air Cork, Water Cork, Cup Grooves, Fans, Power Sockets, Explosion-proof Lighting, Venturi Valve Control, Disc Valve Control

Frequency converter control, color touch screen, film switch, surface wind speed detection, sound and light alarm, all kinds of water and air guns, etc.

Due to the larger space for accessories, please refer to our company for details. We will recommend the accessories and control modes that meet your requirements according to the actual needs of customers.

5.Experience and markets:

KHN is professional lab furniture manufacturer. Products are well sailed all over the world, got many compliments from customers.
